T-962 Reflow Profile Calculator: Simplify Your Soldering Process

I recently acquired a Puhui T-962 reflow oven, which is budget-friendly but requires several modifications to be functional. I installed the replacement firmware by Unified Engineering and replaced the masking tape with kapton tape.

The firmware allows for two custom profiles, with target temperatures specified at 10-second intervals. However, most solder paste datasheets provide temperatures at different intervals, making it challenging to create a precise profile.

For example, MG Chemical’s 4902P low-temp, lead-free paste datasheet provides temperatures at 25-second intervals. To address this, I created a spreadsheet that performs linear interpolation to generate 10-second intervals.

You can download the spreadsheet here. It uses columns A and B for input and columns E through I for additional interpolated times, which are hidden for clarity.

The spreadsheet is licensed under CC-BY-SA, allowing commercial use as long as the copyright notice is retained. I hope this tool saves you time and effort in creating reflow profiles.
